Description

Specifications
Engine / Power Head
• Power Output: 6.2 kW
• Cylinder Displacement: 118.8 cm³
• Maximum Power Speed: 9,000 rpm
• Idling Speed: 2,500 rpm
• Maximum Torque: 7.7 Nm
• Torque at RPM: 6,000 rpm
• Clutch Engagement Speed (±120): 3,400 rpm
• Fuel Consumption: 570 g/kWh
• Fuel Consumption Rate: 3.5 kg/h
• Spark Plug: Champion RCJ7Y, NGK BPMR7A
• Electrode Gap: 0.5 mm
• Ignition Module Air Gap: 0.3 mm
• Oil Pump Type: Automatic
• Oil Pump Capacity (Max): 54 ml/min
• Oil Pump Capacity (Min): 30 ml/min
Equipment
• Bar Length: 0 in
• Recommended Bar Length (Min): 60 cm
• Recommended Bar Length (Max): 105 cm
• Chain Type: —
• Gauge: 1.6 mm
• Pitch: .404″
• Sprocket Type: Rim 7
Dimensions
• Weight (Excl. Cutting Equipment): 10.4 kg
Lubricant
• Engine Lubricant Type: Husqvarna 2-Stroke or equivalent (50:1 mix)
• Oil Tank Volume: 1.48 US pint / 0.7 L
Sound and Noise
• Sound Power Level, Guaranteed (LWA): 116 dB(A)
• Sound Power Level, Measured: 115 dB(A)
• Sound Pressure Level at Operator’s Ear: 102 dB(A)
Vibration
• Equivalent Vibration Level, Front Handle (ahv, eq): 6.7 m/s²
• Equivalent Vibration Level, Rear Handle (ahv, eq): 7.8 m/s²
